Product 1
I: Inverter Silent Type ①
II: Inverter Silent Type ②
III: Standard Fixed Type
Parametets 2
Parameters | I: Inverter Silent Type ① | II: Inverter Silent Type ①② | III: Standard Fixed Type | |
Whole | Model | HQ2QF-HS2000i | HQ2QF-YH2000i |
HQ2QF-YH2500 |
Engine | Model | 149F | YH148F |
168FB |
Type |
Four-Stroke, Overhead Valve, Single Cylinder, Forced Air Cooling |
Single Cylinder, Four-Stroke, Forced Air Cooling, Overhead Valve |
Single Cylinder, Four-Stroke, Forced Air Cooling, Overhead Valve 25° | |
Placement (cm³) | 79.7 | 79 |
196 | |
Bore × Stroke (mm) | 48.6×43.0 | / | / | |
Compression Ratio | 8.7:1 | / | / | |
Rated RPM (kW/min-¹) | 2.3/4500 | / | ||
Ignition System |
Full Crystal Electronic Ignition |
/ |
Contactless Transistor |
|
Start System |
Manual Recoil Start |
Manual Start |
Manual Start | |
Gasoline Type | Unleaded Gasoline | Unleaded Gasoline | Unleaded Gasoline | |
Lubricating Oil Type | SF 15W-40 | SF 15W-40 |
SF 15W-40 | |
Generator | Rated Frequency (Hz) | 50 ▏ 50 | 50/60 |
50 |
Rated Voltage (V) | 230 ▏ 220 | 230/120V |
230 | |
Rated Current (A) | 6.9 ▏ 7.3 | / | / | |
Rated RPM (min-¹) | 4500 | / | / | |
Rated Output Power (kW) |
1.6 | 1.6 |
2 | |
Maximum Rated Power (kW) |
2.0 | 1.8 |
2.2 | |
DC Output | 12V, 5A | 12V, 8.3A |
/ | |
USB Output | / | 5V, 1A | / | |
Overload Protection DC AC |
Fuse-Free Overcurrent Protector AC Overcurrent Protection Program Control |
Fuse-Free Overcurrent Protector AC Overcurrent Protection Program Control |
||
Generator Set |
Gasoline Tank Capacity (L) |
3 | 4.0 | 15 |
Continuous Running Time (h) |
3 (Rated Power) | 4 | 12 | |
Gasoline Consumption Ratio (g/(kw.h)) |
≤560 | / |
/ | |
Operating Ambient Temperature (℃) |
-15~40 | / | ||
Maximum Operating Altitude (m) |
1000 | / | ||
※Noise (dB/4m) LWA | 90 | / | ||
※※Noise (dB/7m) LPA | 61 | 63.5 | / | |
Overall Dimensions (L×W×H) (mm) |
507×285×451 | 500×285×455 |
590×430×440 | |
Net Weight (kg) | 20 | 21 | 42 | |
Standard Implemented | Q/1300 LHZ002-2013 | / |
